Dayton Audio E150HE-44
5" Epique MMAG Extended Range Subwoofer
| Size | 5" |
| Impedance | 44 Ω |
| Power | 200 W |
| MSRP | $119.98 |
| Used in | 0 designs |
Factory specs
From the manufacturer's datasheet
- Re DC resistance
- 6.6 Ω
- Fs Resonance frequency
- 40 Hz
- Qms Mechanical Q
- 2.94
- Qes Electrical Q
- 0.45
- Qts Total Q
- 0.39
- Mms Moving mass
- 26.6 g
- Cms Suspension compliance
- 0.6 mm/N
- Vas Equivalent volume
- 7.64555 L
- Sd Piston area
- 95 cm²
- BL Force factor
- 9.8 T·m
- Xmax Linear excursion
- 14.7 mm
- Le Voice-coil inductance
- 1.6 mH
- SPL_2V83 Sensitivity (2.83 V/1 m)
- 83.3 dB (2.83 V/1 m)
- Vd Displaced volume
- 139.7 cm³
Measured response
About this driver
Featuring a carbon fiber cone, dual voice coils, custom tooled suspension, FEA optimized motor, cast aluminum frame, ample venting, and extensive induction control, the E150HE-44 pushes the limits of performance for a 5-1/2" driver. Capable of exceptional performance in everything from small subwoofers to 2-way designs, this versatile driver will redefine what is possible from compact speaker systems.
MMAG = Multiple Magnet Air Gap
The heart of the E150HE-44 is the patented MMAG dual gap motor assembly. This unique design uses 2 top plates spaced between 6 smaller gap balancing magnets creating more dynamically stable magnetic gaps with more consistent flux than the more common dual gap arrangements. The combination of the MMAG motor and the underhung voice coil gives the E150HE-44 zero loss of motor force (Bl) even when driven to 10 mm of excursion, and an overall excursion capability of over 14 mm (at 70% Bl). This incredible excursion capability allows extremely low harmonic and intermodulation distortion to ensure remarkably clean output even when driven to high output levels. Furthermore, the motor includes a full length copper sleeve surrounding the pole which offers extensive induction control to lower Le and improve high frequency response, while simultaneously lowering distortion, reducing power compression, and increasing thermal power handling.
The rigid carbon fiber cone gives the E150HE-44 a unique look while offering a number of performance advantages. With one of the highest strength to weight ratios of readily available materials, carbon fiber keeps the moving mass to a minimum enabling extended low frequency extension without sacrificing efficiency. The woven cone has excellent damping properties which keeps unwanted resonances under control for incredibly smooth response all the way up to 4,000 Hz. Optimized cone and dustcap profiles make sure that there is no deformation when exposed to high stress so the smooth response and low distortion remains consistent even when pushed to high output levels. Finally, the outside edge of the cone has been reinforced to further control cone breakup and help maintain controlled off axis dispersion.
When designing the E150HE-44, Dayton Audio paid extra attention to optimize the suspension to guarantee unrestricted excursion without limiting performance. The large roll rubber surround was custom tooled for high excursion while paying extra attention to the profile to avoid limiting off axis dispersion. A filleted inside edge helps to add extra damping to the cone while reducing reflection from the high roll surround to further improve higher frequency response. A large diameter progressive spider helps keep the cone linear when driven to high excursion without restriction. In addition, the tinsel leads have been woven into the spider on opposing sides to keep mass and compliance displaced evenly across the spider.
Excess heat build up will increase resistance and cause significant power compression and even failure. The force air across the voice coil and keep everything cool the E150HE-44 has extensive cooling. Another advantage of this MMAG motor assembly is the open spaces between the bucking magnets which allow unrestricted airflow directly into the center of the magnetic gap. With this open layout cool air is pulled directly across the voice coil to remove heat more efficiently than more common motor designs. Also the E150HE-44 includes a vented voice coil former, 3 large peripheral gap vents, and unrestricted airflow under the spider to make sure that every component has fresh air moving across it to keep temperatures at a minimum even when pushed hard for long periods.
In order to support its massive motor assembly while providing a solid mounting surface, the E150HE-44 uses a rugged cast aluminum frame. The minimalistic design of the frame eliminates unwanted reflections and provides ample airflow for the rear of the cone. With plenty of space behind the spider makes sure that you can push the limits of excursion without bottoming out. Being a non-magnetic material, the aluminum frame has no effect to the magnetic field allowing the motor to effortlessly perform exactly as designed. As an added bonus aluminum is an excellent conductor of heat to further assist in cooling.
Thanks to the 14.7mm linear excursion of the E150HE-44, speaker designers can get incredible volume displacement out of a significantly smaller driver in significantly smaller boxes. This comes with a caveat, however; more displacement requires larger ports, which can become cumbersome to fit inside such small boxes.
Used in designs
No published design uses this driver yet.
Downloads
Free, no login neededVersions
Frequency response files
| E150HE-44@0.frd | FRD frequency response | 9 KB |
| E150HE-44@15.frd | FRD frequency response | 9 KB |
| E150HE-44@45.frd | FRD frequency response | 9 KB |
| E150HE-44@30.frd | FRD frequency response | 9 KB |
| E150HE-44@60.frd | FRD frequency response | 9 KB |
Impedance files
| E150HE-44.zma | ZMA impedance | 12 KB |
| E150HE-44_clio.txt | Text | 12 KB |
| E150HE-44_dats.txt | Text | 12 KB |
Other measurement files
| 295-102--epique-e150he-44-mechanical-drawing.pdf | PDF document | 183 KB |
| E150HE-44_3D-Files.zip | ZIP archive | 5.7 MB |
| epique-e150he-44-spec-sheet.pdf | PDF document | 2.6 MB |
